Home screen
Menu screen
Menu-2
Menu-1
Linkage menu
Servo view
For S-FHSS (analog) system,
channels 1 through 7 are dis-
played.
62
Function
Servo View
Servo operation of each channel can be checked. Operation of the steering angle adjust-
ment, when a mixing function was set, etc. can be easily checked.
Servo View
1
Operating each channel, such as a steering stick or throttle stick, the graph moves and the
servo operation can be confi rmed.
2
When fi nished, return to the Linkage menu screen by pressing the HOME button.
Confi rm operation
To Next Page
