17
Before Using
Battery
cover
Caution
When closing the battery cover, be careful that the battery cover does not pinch the battery lead
wires.
Shorting of the battery lead wires may lead to fi re and abnormal heating and cause burns or fi re disaster.
Battery Replacement Method
1
Refer to the previous description and remove
the transmitter battery cover.
When Using The Optional Battery
When using an optional rechargeable battery, replace the battery as described below.
-Always use the optional FT2F1700B , FT2F2100B or HT5F-1800B rechargeable battery.
-The type of power source used must be selected through the system setting (page 180).
-When the transmitter will not be used for a long time, remove the battery.
2
After removing the dry cell battery box from the
transmitter, disconnect the connector.
3
Insert the connector of the new battery and load
the new battery into the transmitter.
4
Finish by installing the battery cover.
While holding down these two points, remove
the battery cover in the direction of the arrow.
To Next Page
