FUTABA 7XC - Page 110

Can be switch between
groups 1 and 2 with the
group change switch.
When changing the gain with
the switch, indicated on the
home screen for a few sec-
onds.
* Display the current gyro gain.
110
Function
Gyro Mixing
3
(Gyro mixing type selection)
Tap the Gyro type and select [1 gain], [2
gain] or [4 gain].
"1 gain" :One mode only
"2 gain" :Switching Gyro gain 1 and Gyro gain 2
"4 gain" :Set 4 Gyro gains.
2 groups of 2 gains can be set in one
group.
Set the switch to change the group and
the switch to change the gain in the
group. (Use to 2 switch)
4
(Gyro gain adjustment)
Tap the value button of each the [Gain]. Val-
ue input buttons appear on the screen, use
the [+] and [-] buttons to adjust the brake
rate amount.
If you tap "Normal" or "AVCS" when the
value is other than "0", Normal / AVCS is
changed.
5
When fi nished, return to the Mixing menu screen by pressing the HOME button twice.
The gain amount can be adjusted with digital trim DT1 to DT6 or digital dial DL1, with
the
"
Trim / Dial select
"
function (page 64).
Dial / Trim Setting
Setting
- Tap Gain type.
1 gain/ 2 gain/ 4 gain
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Gyro gain
Normal:0~120
AVCS:0~120
Initial value: Normal 50
