FUTABA 7XC - Page 112

Type 2
Front side only, Reverse
phase switching
Type 3
Front side only, Reverse phase
and same phase switching
Type 4
Front side only, reverse phase, same
phase, and rear side only switching
112
Function
4WS Mixing
2
(Channel setup)
The channel list screen used for rear steering is displayed. Tap the auxiliary channel that
connected the servo of rear steering.
- When all channels are in use, a screen saying "No assignable channel" is displayed, please turn off other mixing
and make an unused channel. You can check the mixing used on the channel setting screen (page 73).
- T7XC can also be used for rear steering by setting the throttle to another auxiliary channels setting function and
making Ch.2 assignable channel (page 73).
3
(4WS type selection)
Tap the 4WS type and select [Type 1], [Type 2], [Type 3]or
[Type 4].
"Type 1" :Function OFF (front only)
"Type 2" :Front side only, reverse phase switching
"Type 3" :Front side only, reverse phase and same phase switching
"Type 4" : Front side only, reverse phase, same phase, and rear side only switching
Switched in the order shown in the fi gure below by assigned
switch.
For S-FHSS (analog)
system, channels 5, 6
and 7 are displayed.
If there is no assignable
channel, tap [Close]. Turn
off other mixing and make
assignable channels.
To set the throttle
to another auxiliary
channel and use it
for steering 2, tap
[Yes]. To cancel,
[No] is tapped.
Setting
- Tap 4WS type.
Type 1/ Type 2/ Type 3/ Type 4
