113
Function
4WS Mixing
4
(Rear side travel adjustment)
Tap the value button of the [Rear mix rate].
Value input buttons appear on the screen,
use the [+] and [-] buttons to adjust the
rear side travel amount.
5
(Mix mode setting)
Tap "MIX mode" (ON) or (OFF) to select ON
/ OFF.
"OFF" :The EXP function of the 1st CH and other settings are not mixed.
"ON" :The EXP function of the 1st CH and other settings are mixed.
6
When finished, return to the Mixing menu screen by pressing the HOME button twice.
The mixing amount can be adjusted with digital trim DT1 to DT6 or digital dial DL1,
with the
"
Trim / Dial select
"
function (page 64).
Dial / Trim Setting
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Rear rate (Rear mix rate)
0~100
Initial value:100
Setting
- Tap (ON) / (OFF).
To Next Page
