*Shows the ON/OFF state
Adjust button
Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Idle-up rate
-50~0~+50
Initial value: 0
71
Function
Idle-Up
(Preparation)
- Use the switch select function to the "Switch
select" (page 67).
When the switch is not set "A switch is not
assigned" is displayed. Tap [Switch select] to
display the switch selection screen and set the
switch.
Idle-up function adjustment
1
(Idle-up rate)
Tap the rate value button. The value input
button is displayed on the screen, and use
the [+] and [-] buttons to adjust the amount of
the neutral brake rate.
The Idle-up rate can be adjusted with digital trim DT1 to DT6 or digital dial DL1, with
the
"
Trim / Dial select
"
function (page 64).
Dial / Trim Setting
2
When finished, return to the Linkage menu screen by pressing the HOME button.
