FUTABA 7XC - Page 79

* The vertical cursor line moves in
conjunction with the operation of
the throttle stick.
* The vertical cursor line moves in
conjunction with the operation of
the throttle stick.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Curve rate
-100~+100
Initial value : 0
Point
1~99
Initial value : 50
79
Function
Curve (EXP)
(Preparation)
-Tap the curve type and select [EXP].
1
Tap the value button of the [EXP rate].
Value input buttons appear on the screen.
When you want to quicken Throttle opera-
tion, use the [+] button to adjust the + side.
When you want to make Throttle operation
milder, use the [-] button to adjust the - side.
If you tap "Quick" or "Mild" when the value
is other than "0", Quick / Mild is reversed.
2
When finished, return to the Racing menu screen by press-
ing the HOME button twice.
Adjustment method for EXP curve
(Preparation)
-Tap the curve type and select [VTR].
1
Tap the value button of the [VTR rate].
Value input buttons appear on the screen.
When you want to quicken throttle opera-
tion, use the [+] button to adjust the + side.
When you want to make throttle operation
milder, use the [-] button to adjust the - side.
If you tap "Quick" or "Mild" when the value
is other than "0", Quick / Mild is reversed.
2
Curve switching point adjustment
Tap the value button of the [Point]. Value input buttons ap-
pear on the screen, use the [+] or [-] buttons to move to the
point you want to set.
Throttle VTR adjustment
3
When finished, return to the Racing menu screen by pressing the HOME button twice.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Curve rate
-100~+100
Initial value : 0
The throttle
"
EXP
"
,
"
VTR
"
adjustment can be adjusted with digital trim DT1 to DT6 or
digital dial DL1, with the
"
Trim / Dial select
"
function (page 64).
Dial / Trim Setting
