4. Power up the CS208 / CS216 input expander
6.2.2.1 DIP switch 6 (CS216 only)
To disable the second group of 8 zones on the CS216 input expander, turn DIP switch 6 on. This should be done
only if you need an 8-zone expander in a particular location.
For details on how to install the CS208 / CS216 input expander in the various housings, chapter A-4 Installing a
basic system.
Table 6-1: CS208 / CS216 input expander DIP switches
DIP
switch setting
Starting
zone
number
Module
number
DIP
switch setting
Starting
zone
number
Module
number
9 23 89 99
17 16 97 100
25 17 105 101
33 18 113 102
41 19 121 103
49 20 129 104
57 21 137 105
65 96 145 106
73 97 153 107
81 98 161 108
= ON = OFF
