CS875-575-375-275-175 Installers Manual with CS5500 keypadB.7.5
Table 7-3: CS507 output expander output events
# Event # Event # Event
Tampers Misc Communications
9 Mains Failure 8 Any Bypass 32 Listen-in
10 Low Battery 11 Duress 33 Line Seizure
25 Fire LED 45 Code Entry 34 Failed to communicate
26 Fire Trouble 36 Program Mode 35 Telephone line fault
28 Expander Trouble 46 Keyfob Funct 1 37 Download
39 Over-current 47 Keyfob Funct 2 55 End Listen In (Integrated
Only)
40 Box Tamper 51 CS507 Schedule
Arm/disarm
41 Siren Tamper 52 X-10 Alarm Mem 18 Entry
42 Any Open Zone 53 X-10 Siren 19 Exit
58 Sensor Low Battery 56 Compare X10 Commands To
Programmed Outputs
20 Entry or exit
59 Sensor Lost
Keypads 21 Armed
64 Smoke Reset Function 12 Manual Fire 22 Not armed
65 Antimask Output 13 Keypad Medical 23 Ready
Alarms 14 Keypad panic 24 Not ready
0 Burglary Alarm 15 Keypad tamper 30 * Open schedule
1 Fire Alarm 27 Chime 31 * Closed schedule
2 24-hour Alarm 44 Keypad beeping 48 Auto arm control
3 Trouble Alarm
Sirens 49 Auto disarm control
4 Tamper Alarm 5 Burglary Siren 50 Auto arm and disarm control
17 Alarm memory 6 Fire Siren 54 Armed Away With Exit
Expired
43 Any Alarm 7 Any Siren 57 Armed Stay
62 Verified Burg 61 External Siren
Tests
63 Verfied Fire 16 Automatic Test
29 Dyn Battery Test
60 Walktest Mode
*
See Schedule Times>Opening and Schedule Times>Closing/Autoarm.
If set to latched condition, these events are one second
.
Events 46 and 47 require RX8w8, RX16w8, RX32w8, RX8i4, RX16i4, or RX48i4 wireless receivers to operate.
Events 48, 49 and 50 arm or disarm the CSx75 at the open (disarm) or close (arm) time for the appropriate schedule.
<
For events 48 and 50, the keypad buzzer will sound one minute prior to auto arm if the zone value is 1.If the zone
value is 0, the keypad will not sound prior to auto arm
To Next Page
