CS875-575-375-275-175 Installers Manual with CS5500 keypad B.12.7
12.1.2.2 House Code A menu option that sets the code used to identify a particular premises. It is
necessary in case any neighbouring premises also has an X-10 home
automation system.
More information on the X-10 home automation system can be found at
www.x-10europe.com.
12.1.2.3 Functions A menu entry that groups the functions that can be linked between a CS1700
proximity reader and X-10 functions.
12.1.2.3.1 Single Badge (1 Beep) A menu option that sets the X-10 function sent when a proximity card is held
against the proximity reader once.
12.1.2.3.2 Double Badge (2 Beeps) A menu option that sets the X-10 function sent when a proximity card is held
against the proximity reader twice within the time set in Badge Hold.
12.1.2.3.3 Badge Hold (3 Beeps) A menu option that sets the X-10 function sent when a proximity card is held
near the proximity reader for longer than the time set in Badge Hold.
12.1.3 Feature Select A menu entry that groups all optional features relating to the selected proximity
reader.
12.1.3.1 User Card Programming A menu option that enables user cards to be programmed.
12.1.3.2 Optical Tamper A menu option that sends a report to the central station when there is
interference with the proximity reader. The optical tamper is built in as a pry-off
protection.
12.1.3.3 Buzzer Follows Keypad A menu option that makes the reader buzzer settings the same as the keypad
buzzer settings.
12.1.3.4 Ding Dong Chime A menu option that enables a ding dong chime.
12.1.3.5 Log RTE (Card) A menu option that records an RTE (Card) event in the event log. An RTE
(Card) event is a request to exit by scanning a card.
12.1.3.6 Log RTE (Zone) A menu option that records an RTE (Zone) event in the event log. An RTE
(Zone) event is a request to exit by activating a zone.
12.1.3.7 Card Scan Mode A menu option that switches between the old and new scanning mode. The old
mode is displayed as Single/Double/Hold and the new mode is displayed as 1/
2/3 Beeps.
12.1.4 Access Options A menu entry that groups access options for the selected proximity reader.
12.1.4.1 Maglock or Drop Bolt Lock A menu option that controls a maglock or drop bolt lock. When a door zone is
programmed and this option is enabled, the proximity reader monitors the door
zone and waits for a couple of seconds after the door is closed before
activating the lock. This is to prevent a door slamming shut due to a maglock or
not getting shut at all due to the premature locking of a drop bolt.
12.1.4.2 Allow Access While Armed A menu option that enables a user to activate/deactivate the selected proximity
reader while the system is armed.
12.1.4.3 Don’t Stay Unlocked While Open A menu option that prevents a door which has been opened during the open
period from staying open.
12.1.4.4 Only if Open A menu option that activates the selected proximity reader between opening
time and closing time. During these times, a card can be used to arm/disarm
the system. A timer is used to set these times.
12.1.4.5 Only if Closed A menu option that activates the selected proximity reader after closing time
and before opening time. During these times, a card can be used to arm/
disarm the system. A timer is used to set these times.
Location Term Definition
