GE Security CS575 User Manual

CS875-575-375-275-175 Installers Manual with CS5500 keypadA.4.5
- Connect the CS534 listen-in module to the box.
- Flip down the PCB mounting tray.
- Attach the pillars for the CS535 voice module to the board.
- Attach the CS535 voice module to the board via the jumpers and pillars.
- Connect the CS534 listen-in module and CS535 voice module with the ribbon cable.
7. Attach the pillars for the CS208 / CS216 input expander or CS507 output module to the board.
8. Mount the CS208 / CS216 input expander or CS507 output module on the board.
9. Drill 0.3 mm holes for the card guides in the box.
10. Place the card guide (NX-CA-SL) in the box.
CS275/375/575/875
CS275/375/575/875
CS275/375/575/875
CS275/375/575/875
CS275/375/575/875
CS534
CS535
CS535
CS507
CS216
CS535
CS216
CS507
