5.2 Mixer
Required tools
DimensionTool
T20Torx screwdriver
Instructions
Follow the instructions below to remove and replace the Mixer.
WARNING
Disconnect power. Always switch off power to the instrument be-
fore replacing any component on the instrument or cleaning the
instrument, unless stated otherwise in the user documentation.
ActionStep
Switch off the instrument by pressing the Power Switch to the O position.1
Remove the inlet and outlet tubing from the ports.2
114 ÄKTA start Maintenance Manual 29060308 AD
5 Removing and replacing modules
5.2 Mixer
