2.2 Instrument
Introduction
This section provides an overview of ÄKTA start modules.
Illustration of the instrument
modules
The illustration below shows the locations and gives brief descriptions of the modules
placed on the wet side of the instrument.
1
2
3
4 5
6
7
8 9 10
DescriptionFunctionPart
A 3-port valve that is used as a switching valve for
gradient formation using two buffers.
Buffer valve1
A static mixer that is used for mixing buffers A and
B.
Mixer2
