2.1 System overview
Introduction
ÄKTA start is operated and controlled from the Instrument Display. In addition, the
UNICORN start software can be used to control ÄKTA start and to analyze the data ac-
quired during chromatography runs. UNICORN start offers several additional features
that are described in detail in UNICORN start User Manual.
This section gives an overview of the ÄKTA start System.
Illustration of the system
The illustration below shows the ÄKTA start System with UNICORN start installed on a
computer.
1 23
DescriptionPart
ÄKTA start (instrument).1
Frac30 (Fraction collector).2
UNICORN start (software installed on a computer).3
14 ÄKTA start Maintenance Manual 29060308 AD
2 System description
2.1 System overview
