Tubing and pressures
The table below shows the tubing to disconnect when checking and calibrating the pressure monitors.
The UNICORN names of the pressures measured by the monitors are also shown.
Pressure in UNICORNTubing to disconnectPressure monitor
System pressureTubing from the System pump pressure monitorSystem pump pressure
monitor
Sample pressureTubing from the Sample pump pressure monitorSample pump pressure
monitor
PreC pressureTubing to Column valve V9-C or V9H-C port InPre-column pressure
monitor
306 ÄKTA pure User Manual 29119969 AB
7 Maintenance
7.7 Calibration procedures
7.7.2 Calibrate the pressure monitors
