Connect tubing
The table below shows recommended tubing and connectors.
Tubing
length
(mm)
ConnectorTubingConnectionTubing
label
ÄKTA pure 150ÄKTA pure 25
135Fingertight connector,
1/16"
PEEK, o.d. 1/16",
i.d. 0.75 mm
PEEK, o.d. 1/16",
i.d. 0.50 mm
Flow restrictor to
Outlet valve
9
160Fingertight connector,
1/16"
PEEK, o.d. 1/16",
i.d. 0.75 mm
PEEK, o.d. 1/16",
i.d. 0.50 mm
pH valve to
Outlet valve
9pH
1500Fingertight connector,
1/16"
ETFE, o.d. 1/8",
i.d. 1 mm
ETFE, o.d. 1/8",
i.d. 1 mm
Outlets from the
outlet valves
Out1 -
Out10
If ÄKTA pure previously has been configured without an Outlet valve, remove the Union F/F
between tubing 9 and tubing W before installation of the Outlet valve. Then connect tubing 9
to the In port on the Outlet valve and the waste tubing W to the W port on the Outlet valve.
