Tubing holder comb
The Tubing holder comb is used to hold and arrange tubing.
The illustration below shows the Tubing holder comb.
DescriptionPart
1
2
3
Positions for tubing1
Tab2
Snap-in to holder rails3
Bottle holder
The Bottle holder is used for holding bottles. For example, the Bottle holder can be attached to the
holder rails to hold a sample bottle.
The illustration below shows the Bottle holder.
DescriptionPart
1
2
Position for bottle1
Snap-in to holder rails2
Adapter for air sensor
The adapter for air sensor is used to hold an optional air sensor.
The air sensor with adapter is connected to the Bottle holder, see illustrations below.
DescriptionPart
1
2
3
Air sensor1
Air sensor adapter2
Bottle holder3
84 ÄKTA pure User Manual 29119969 AB
2 The ÄKTA pure instrument
2.6 Accessories
