Dispenser head
The illustration below shows the Dispenser head of Fraction collector F9-C.
1 2 3
4
56
DescriptionPart
Dispenser head1
Nozzle2
Dispenser head cover3
Accumulator (back part of Dispenser head)4
Drop sync sensor5
Type code reader6
