7.10.8 eVap Communication troubleshooting
Flowchart 23
Problem Continues?
Does either LED indicate
Activity during Start-up?
Does the eVap communicate
in the software download
mode?
Start
Yes
Perform Software
Download.
Check the ADB
TXD / RXD LEDs
Can the issue be
duplicated?
TXD
RXD Only or No Activity
No
Contact Technical
Support.
No
Check / Replace
ACB to Pan Cable
and Pan to eVap
Cable.
Problem Solved
Yes
Check / Replace
Cabling. Replace
ACB if problem
persists.
Replace ADB
Board.
Is the Mixer functioning?
No
Troubleshoot
Mixer.
Yes
No
Problem Continues?
Replace the PAN
Connector Board.
Yes
No
Error Log Entry
COM ERROR VENT TO ACB
Compatibility failure: DCB hardware
VAPORIZER LOST MIXER FLOW
VAPORIZER SUBSYSTEM COMM FAILURE
Yes
Symptom
AB.75.180
