Aisys
2-28 04/08 M1046983
2.10 Electronic Vaporizer
The electronically controlled vaporizer consists of the internal electronic vaporization
subsystem and the Aladin agent cassette. The agent cassettes are color coded, have
indexed filling ports, and are magnetically coded for each agent. The electronic control
unit governs the flow through the agent cassette and the agent concentration in the
fresh gas flow.
Both the Aladin
2
and the Aladin cassettes can be used on this system.
2.10.1 Agent
cassette
Aladin DES and all Aladin
2
cassettes have electronic agent level sensing. The agent
level shows graphically in the agent settings area of the screen.
If the agent level is not available electronically, the agent level unknown symbol
shows on the screen. In this case, refer to the liquid level indicator.
Some Aladin
2
cassettes have internal temperature sensing. If available, an
enhanced temperature sensing symbol shows on the front of the cassette and
the symbol shows in the agent settings area of the screen.
There are three types of Aladin
2
cassette filler systems. Enflurane, and isoflurane use a
color-coded, Easy-Fil mechanism. Sevoflurane cassettes are available with a color-
coded, Easy-Fil or Quik-Fil mechanism. The desflurane cassettes have a filling
mechanism that is compatible with Saf-T-Fil desflurane bottles.
Note Sevoflurane Quik-Fil Aladin
2
cassettes are not available in all countries.
Anesthetic agent Filling system Color code
Enflurane Easy-Fil Orange
Isoflurane Easy-Fil Purple
Sevoflurane Easy-Fil or Quik-Fil Yellow
Desflurane Compatible with Saf-T-Fil Blue
