GE Datex-Ohmeda Aisys Carestation User Manual

Aisys
2-42 04/08 M1046983
2.11.3 Physical
connections
(O
2
supply)
Figure 2-30 shows the physical path
that the O
2
gas supply takes. The item
numbers are described in Figure 2-29.
Figure 2-30 • Typical (O
2
) tubing connections - pictorial
19
ACGO
ABS
Port 3
22
P
Air
N
2
O
O
2
N
2
O
Alt
O
2
O
2
Air
P
P
Select
Disable
Balance
Gas Flow
SelectSelect
O
2
Flow
PP
Mixer
SCGO
ABS
Port 2
Port 3
Pilot
SCGO
To Vent Drive
2
1
3
4a
7
7
9
10
11b
11c
11a
12a
14a
14b
15
19
4
24
8 8
6
6
SCM
23
22
Suction
AB.75.173m
Venturi Drive
Pilot
Vacuum
Power
Outlet
12b
13

GE Datex-Ohmeda Aisys Carestation Specifications

General

Type	Anesthesia Machine
Manufacturer	GE Healthcare
Model	Aisys Carestation
Power Requirements	100-240V AC, 50/60 Hz
Display	High-resolution color touchscreen
Ventilator Type	Electronically controlled ventilator
Ventilation Modes	Volume Control, Pressure Control, SIMV, Pressure Support, Manual
Gas Delivery	Oxygen, Nitrous Oxide, Medical Air
Power Supply	AC mains, Battery backup
Integrated Monitoring	Yes
Communication	Ethernet
Connectivity	Ethernet
Alarms	Comprehensive alarm system for ventilation, gas delivery, and patient monitoring parameters
