DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
3 - 36 Section 3-5 - Configuration
3-5-3 Optional Peripherals/Peripheral Connection
Approved Internal Peripherals (Optional)
This list covers the internal peripherals available for the LOGIQ E10.
• 4D Option USB Flash Drive
• Black and White Printer
• CW Option
• Patient I O ECG Option
• Power Assistant Option
• Shear Wave Option
• Software DVR
• V Nav Option
•WLAN
Approved External Peripherals (Optional)
The external printers are connected through Ethernet (TCP/IP Network) as DICOM devices.
• DICOM Printers. Connected through Ethernet (TCP/IP Network or WLAN) as DICOM devices.
• USB Printers, see: 9-14-1 "Printers" on page 9-31.
• USB Footswitch
• Rolling V Nav Stand
•Color Printer
• Report Printer
Additional Information
See: Section 9-14 "Peripherals" on page 9-31 for replacement units.
Printer Checks
Check to see if the printer works as described in Table 3-8.
Table 3-8 Peripheral Checks
Step Task Note
1.
Press Freeze. Stops image acquisition.
2.
Press (Print 1), (Print 2), (Print 3) or (Print 4) on
the control panel.
Prints image displayed on the screen on a black and white or color
printer, depending on the key assignment configuration.
To Next Page
