GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 3 LOGIQ E10 Setup 3 - 37
3-5-4 Software Options Configuration
Software Option Installation
A password (Software Option String) enables a software option or a combination of software options.
This password is specific for each LOGIQ E10.
Installing a Software Option
NOTE: Before you install a software option, you must login.
After you have established your password, follow these steps to login.
1.) Type your user name in the Operator field.
2.) Type your password in the Password field.
3.) Press OK to login, or Cancel to cancel login.
Figure 3-23 Login Window

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
