GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 90 Section 8-7 - Replacing Top Console Parts
Calibration and adjustments
See: Section 6-2 "Monitor adjustments" on page 6-2 for Main Monitor calibration instructions and/or
Monitor Arm and Monitor Friction Adjustment.
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) Connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
NOTE: The Wide Screen Monitor may need a second reboot for the system to fully identify the
monitor’s USB device. To confirm, verify that the Monitor Controls for the Wide Screen Monitors
are available on the Touch Panel Utility pages.
Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
Table 8-104 Main Monitor assembly replacement Functional Checks
See:
Section
Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Leakage Current
measured at (record the value) and meets
allowable limits. Equipment passed all required
checks and is ready for use.
4-2-7 B-Mode Checks
4-2-7 System CFM and PWD Checks
10-7-4 Grounding continuity
10-7-5 Chassis leakage current test
4-2-4 Power SHUT DOWN

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
