Chapter 8 Replacement Procedures 8 - 105
Calibration and adjustments
See: Section 6-2 "Monitor adjustments" on page 6-2 for Main Monitor calibration instructions.
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) Connect cables and Probes removed earlier.
3.) Power up the LOGIQ E10 to verify that it operates as intended.
Functional Checks
Perform the following functional tests to confirm the LOGIQ E10 is operational before returning the
LOGIQ E10 to the customer.
Table 8-114 Main Monitor Arm Assembly Adapter replacement
Functional Checks
See:
Section Functional Checks Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Leakage Current
measured at (record the value) and meets
allowable limits. Equipment passed all required
checks and is ready for use.
4-2-7 B-Mode Checks
4-2-7 System CFM and PWD Checks
10-7-4 Grounding continuity
10-7-5 Chassis leakage current test
4-2-4 Power SHUT DOWN
