DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 124 Section 8-7 - Replacing Top Console Parts
4. Lift the front edge and gently flex
the Lower OP up and slide it slightly
up and away from the Lower OP
Frame.
Place the OP on an ESD safe place.
Table 8-142 Lower OP removal
Steps Corresponding Graphic
To Next Page
