Lower Bezel Installation
Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) Connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
4.) Select comments and type different A/N keys to confirm keyboard functionality.
Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
Table 8-168 Lower Bezel Installation
Steps Corresponding Graphic
1. Set the new Bezel in place.
2. Install the screws to reattach the Boards.
Re-connect the boards Signal Cable, re-install the removed Encoders and re-connect them.
Re-install the A/N Keyboard.
Before continuing, test the Encoders and Op Panel controls to ensure they operate properly. If
the Encoder seals are too close to the Encoder, the seals can cause the Encoder operation to
bind. If the seals are to high, the can limit the joystick operation.
3. Re-install the Lower OP, Upper OP/Touch Panel Assembly (verify Encoder operation) and all
covers removed.
Table 8-169 Lower Bezel replacement Functional Checks
See:
Section
Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Equipment passed all
required checks and is ready for use.
4-2-7 B-Mode Checks
4-2-7 Probe/Connectors Checks
4-2-7 System CFM and PWD Checks
4-2-7 Basic Measurements
Joysticks
4-2-4 Power SHUT DOWN
