Backplane installation
CAUTION
To avoid injury, handle the Backplane by the edges. There are two guides to guide the ECB onto the
Backplane, which protrude and are VERY SHARP.
Table 8-330 Backplane installation
Steps Corresponding Graphic
1. Grasping the outer edges of the Backplane, carefully place the Backplane toward the Card Cage,
guiding the connectors to the Main Power Supply into the Card Cage.
Install the 21 Phillips screws to secure and ground the Backplane to the Card Cage. Tighten
screws alternately.
2. Re-connect the Subwoofer audio cable to J9 on the Backplane.
3. Re-install the Option Bracket. BE SURE to support the Bracket as it is being installed, it has
mass.
Re-install the five M6 screws that secure the Option Bracket to the Base Casting, loosely.
4. Re-install the four hex screwlocks (on the right) and two locking posts (on the left) to the
Connector Panel Torque to 0.6 +/- 0.1 Nm (0.4 +/- 0.07 lbf-ft).
Starting at the top, re-install the 7 Phillips screws that secure the Option Bracket to the Card
Cage. Tighten alternately.
Torque the M6 screws to 3.7 +/- 0.6 Nm (2.7 +/- 0.44 lbf-ft), ONLY the M6 screws are torqued to
this value.
Re-connect Subwoofer to J9, on the Backplane.
5. Position the Option Box up slightly and turn it toward the Main Power Supply to access the
Network Cable at the bottom of the Rear I/O. Re-connect the Network Cable and continue to
position the Option Box onto the studs that secure the Option Box to the Card Cage. Three are
underneath the Option Box, in slots.
Re-install the flange nuts. Tighten all the nuts, alternately, using a 7 mm driver.
6.
Place the Subwoofer cable and grounding clamp into the Option Box.
Re-install the screw to secure the clamp to the Option Box. MAKE SURE the clamp is grounding
the cable.
7.
Re-install the Battery Bracket.
Install the flange nuts and secure the Battery Bracket to the Option Bracket.
8. Install the Battery last.
Re-install all Options and Option covers removed re-connect all cabling to the Backplane and
CW Cable, if present.
9. Re-install Printer Tray and Printer or Printer Filler.
10. Re-install Main Power Supply.
11. Re-seat all the boards in the Card Cage.
12. Re-install the Battery Bracket, re-connect the Batteries and install the Battery Cover.
13. Re-install all other covers removed.
