8 - 324 Section 8-11 - Front End Acquisition / Card Cage parts replacement
18. Position the Option Box up slightly and turn it toward the Main Power Supply to access the
Network Cable at the bottom of the Rear I/O. Re-connect the Network Cable and continue to
position the Option Box onto the studs that secure the Option Box to the Card Cage. Three are
underneath the Option Box, in slots.
Re-install the flange nuts. Tighten all the nuts, alternately, using a 7 mm driver.
19.
Place the Subwoofer cable and grounding clamp into the Option Box.
Re-install the screw to secure the clamp to the Option Box. MAKE SURE the clamp is grounding
the cable.
20.
Re-install the Battery Bracket.
Install the flange nut and secure the Battery Bracket to the Option Bracket.
21. Install the Batteries last.
Re-install all Options and Option covers removed, and re-connect all cabling to the Backplane.
22. Re-connect the Batteries and install the Battery Cover.
23. Re-install all other covers removed.
Table 8-334 Connector Panel replacement
Steps Corresponding Graphic

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
