Chapter 8 Replacement Procedures 8 - 325
Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
NOTE: NOT ALL functional checks will have to be repeated, if the functional check was performed
when the previous Option was re-installed. If ONLY a particular Option was removed, perform
the functional checks for the Connector Panel replacement and that particular Option.
Table 8-335 Connector Panel replacement Functional Checks
See:
Section
Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Leakage Current
measured at (record the value) and meets
allowable limits. Equipment passed all required
checks and is ready for use.
4-2-7 B-Mode Checks
4-2-7 System CFM and PWD Checks
4-2-7 Basic Measurements
10-7-4 Grounding continuity
10-7-5 Chassis leakage current test
4-2-4
Power SHUT DOWN
DO NOT POWER SHUT DOWN until ALL
functional checks have been performed
In addition: Perform the following Functional Checks if
the Option was or Options were removed during
Backplane replacement.
4D
4-2-7 Probe/Connectors Checks
Perform a 4D sweep
Continued
