GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 351
Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) Connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
4.) Perform a test print, if Printer is present.
Functional Checks
Table 8-365 Cable Holders - ECB, MPS and Rear I/O replacement Functional
Checks
See:
Section Functional Check Debrief Script
If the MPS or Rear I/O Cable Holder was replaced,
perform the following Functional Checks
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Leakage Current
measured at (record the value) and meets
allowable limits. Equipment passed all required
checks and is ready for use.
4-2-4 Power ON/Boot Up
Probe/Connectors Checks
4-2-7 B-Mode Checks
4-2-7 System CFM and PWD Checks
10-7-4 Grounding continuity
10-7-5 Chassis leakage current test
4-2-5 Top Console checks
Perform a 4D sweep
4-2-4
Power SHUT DOWN
DO NOT POWER SHUT DOWN until ALL
functional checks have been performed, if
required
In addition: Perform the following Functional Checks if
the ECB Cable Holder was replaced
4-2-7 Basic Measurements
4-2-4 Power SHUT DOWN
