DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 355
3.
Remove the flange nut securing the Battery
Bracket Assembly to the Option Bracket,
using a 7 mm driver.
Remove the Tray.
4.
Remove the screw securing the Subwoofer
audio cable grounding clamp to the Option
Box.
Place the cable and clamp below the
Option Box.
Table 8-368 Option Box removal
Steps Corresponding Graphic
To Next Page
