DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 419
4.
Remove the two screws securing the
ECG module.
Slide the ECG module, off the Option
Box.
Table 8-414 Patient I/O ECG Option removal
Steps Corresponding Graphic
