GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 433
Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Connect cables and Probes you removed earlier.
2.) Power up the system to verify that it operates as intended.
Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
Table 8-430 Shear Wave Option replacement Functional Checks
See:
Section
Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, (latest revision). Leakage
Current measured at (record the value) and
meets allowable limits. Equipment passed all
required checks and is ready for use.
4-2-7 Probe/Connectors Checks
4-2-7
Shear Wave Elastography (Shear Elasto)
Functional Checks
10-8-3 Grounding continuity
10-8-4 Chassis Leakage Current Test
4-2-4 Power SHUT DOWN
