GE LOGIQ V1 - Setting up the Off-Line Paper Printer

Performing an Exam
2-70 LOGIQ V2/LOGIQ V1 – User Guide
Direction 5610736-100
Rev. 9
Setting up the Off-Line Paper Printer
You can connect an off-line paper printer via the Isolated USB
port.
Figure 2-34. Patient Environment
CAUTION
ONLY plug in devices to the USB ports located at the rear of
the system WHILE the LOGIQ V2/LOGIQ V1 is NOT powered
up. If you plug in a device while the LOGIQ V2/LOGIQ V1 is
powered on, your system may become unusable.
CAUTION
DO NOT place an off-line paper printer inside the patient
environment. This assures compliance to leakage current.
CAUTION
DO NOT place an off-line paper printer inside the patient
environment (within the dotted line area noted by “1” in
Figure 2-34). Refer to the off-board printer’s manufacture
manual for details.
