GE LOGIQ V1 - Other Peripheral Ports Connection

Getting Started
1-28 LOGIQ V2/LOGIQ V1 – User Guide
Direction 5610736-100
Rev. 9
Peripherals Connection (continued)
3. Other peripheral ports connection
Table 1-4: Other Peripheral ports connection
Peripherals Illustration
SD Card connection
Ethernet connection
HDMI port connection
