CAN ID
The CAN ID is a unit number used by UNICORN to recognize the particular pump unit
that is connected. If more than one pump unit is connected, the units are distinguished
by their CAN IDs.
The CAN ID is set by turning a switch on the pump rear panel (see illustration above).
The switch has four CAN ID positions, marked 1, 2, 3, and 4, respectively. The CAN ID
should be set to position 1 for the first pump, position 2 for the second pump and so on.
The pumps are identified in UNICORN by their CAN ID. Label each pump unit
with its CAN ID to simplify identification of the physical pump.
Tip:
ReadyToProcess WAVE 25 Operating Instructions 29009597 AD 57
3 System description
3.4 ReadyToProcess Pump 25
