gefran SIEIDrive ADL300 Functions Description And Parameters List

ADL300 • Functions description and parameters list 103
Alarm Ignore Warning Disable drive Stop Fast stop
Bres ovld
ü ü ü ü ü
InAir
ü ü ü ü ü
PhLoss
ü ü ü ü ü
Opt Bus
ü ü ü ü ü
Mot PhLoss
ü ü ü ü ü
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.1 4500 Fault reset src LINK 16BIT 6000 0 16384 RW FVS
Selection of the origin (source) of the signal to be used for the command to reset the drive after an alarm. The terminal that
can be used for this function can be selected from among those listed in the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.2 4502 ExtFlt src LINK 16BIT 6000 0 16384 RW FVS
Selection of the origin (source) of the signal to be used as the input for the drive external fault alarm ExtFlt. The terminal
that can be used for this function can be selected from among those listed in the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.3 4504 ExtFlt activity ENUM Disable 0 4 RW FVS
Setting of the behaviour of the drive in the event of an external fault alarm ExtFlt. This alarm indicates the intervention of a
drive external protection.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.4 4506 ExtFlt restart ENUM Disable 0 1 RW FVS
Enabling of automatic restart after the external fault alarm ExtFlt
0 Disable
1 Enable
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.5 4508 ExtFlt restart time ms UINT16 1000 120 30000 RW FVS
Setting of the time within which the External Fault alarm must be reset in order to perform automatic restart.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.6 4510 ExtFlt holdoff ms UINT16 0 0 10000 RW FVS
Setting of the delay between the signalling of the external fault alarm ExtFlt and enabling of the alarm. If an alarm condi-
tion occurs, the drive will wait for the set time before blocking is enabled. If the alarm is removed within the set time, the
drive will not indicate any alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7 4520 MotorOT src LINK 16BIT 6000 0 16384 RW FVS
Selection of the origin (source) of the signal to be used for the motor overtemperature alarm MotorOT. The terminal that
can be used for this function can be selected from among those listed in the “L_DIGSEL2” selection list”.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.8 4522 MotorOT activity ENUM Warning 0 4 RW FVS
Setting of the behaviour of the drive in case of a motor overtemperature alarm MotorOT. This alarm indicates that the mo-
tor temperature is too high.
0 Ignore
1 Warning
2 Disable
3 Stop
