ADL300 • Functions description and parameters list 109
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.49 4680 GroundFault thr perc FLOAT 10.0 0.0 150.0 ERWS FVS
Setting of the threshold for the ground short circuit alarm Ground Fault.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.50 4700 Alarm dig sel 1 ENUM Nessun allarme 0 40 ERW FVS
22.51 4702 Alarm dig sel 2 ENUM Nessun allarme 0 40 ERW FVS
22.52 4704 Alarm dig sel 3 ENUM Nessun allarme 0 40 ERW FVS
22.53 4706 Alarm dig sel 4 ENUM Nessun allarme 0 40 ERW FVS
Setting of the alarm signal to enable on a digital output. The digital output is selected using parameters Alm dig out mon
1÷4, which can be enabled in the L_DIGSEL1 selection list.
0 No alarm
1 Overvoltage
2 Undervoltage
3 Ground fault
4 Overcurrent
5 Desaturation
6 MultiUndervolt
7 MultiOvercurr
8 MultiDesat
9 Heatsink OT
10 HeatsinkS OTUT
11 Intakeair OT
12 Motor OT
13 Drive overload
14 Motor overload
15 Bres overload
16 Phaseloss
17 Opt Bus fault
18 Opt 1 IO fault
19 Opt 2 IO fault
20 Opt Enc fault
21 External fault
22 Speed fbk loss
23 Overspeed
24 Speed ref loss
25 Emg stop alarm
26 Power down
27 Phaseloss out
28 OV safety
29 Safety failure
30 Mot phase loss
31 Ropes change
32 Not Used
33 Plc1 fault
34 Plc2 fault
35 Plc3 fault
36 Plc4 fault
37 Plc5 fault
38 Plc6 fault
39 Plc7 fault
40 Plc8 fault
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.54 4720 Alm autoreset time s FLOAT 0.0 0.0 60.0 ERW FVS
Setting of the time interval that must pass before executing an automatic reset.
If no alarms are enabled the drive is set to restart.
If some alarms are still enabled the drive is set to execute a new attempt at automatic reset.
At each attempted reset a counter increases. If the limit set in the Alm autoreset number parameter is reached the drive is
