28 ADL300 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.4 11012 Pulley diameter m FLOAT 0.60 ERW FVS
Setting of the diameter of the pulley.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.5 11150 Car weight kg FLOAT 0.00 RW FVS
Setting of the weight of the cabin.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.6 11152 Counter weight kg FLOAT 0.00 RW FVS
Setting of the weight of the counterweight.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.7 11154 Load weight kg FLOAT 0.00 RW FVS
Setting of the weight of the maximum load for system dimensions.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.8 11156 Rope weight kg FLOAT 0.00 RW FVS
Setting of the weight of the cable.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.9 11158 Gearbox inertia kgm² FLOAT 0.00 RW FVS
Setting of the inertia of the mechanical reducer.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.10 11160 Motor inertia kgm² FLOAT 0.00 RW FVS
Setting of the motor inertia.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.11 11162 Calc spd reg gains ENUM INT 0 0 1 RW F__
If enabled this writes the inertia value in parameter 2240 Inertia, calculates the gains of the speed loop, sets parameters
2200 to 2210 to 100% and writes the calculated values in parameters 2236 Speed reg P gain, 2238 Speed reg I time and
2242 Bandwidth. The value of the parameter is automatically reset to 0 once calculation starts.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.12 12020 Inertia calculated kgm² FLOAT 0 R FVS
The inertia of the system with half load applied to the motor is displayed. This value can be entered in the Inertia parameter
in the “
16 - SPEED REG GAINS” menu.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.4.13 12022 SpeedLineCalc m/s FLOAT 0 R FVS
The linear speed in m/s calculated using the 11010 Gearbox ratio and 11012 Pulley diameter parameters is displayed.
