ADL300 • Functions description and parameters list 47
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.7.19 11272 Fast Enable sel ENUM 1 0 1 RW FVS
This parameter enables the Fast Enable command to digital Input 8. Entry to Digital Input 8 must be controlled by the con-
troller. The enable should be completed with contactorless operation.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.7.20 11274 Landing Cmd src ENUM NULL - - RW FVS
You can enable the Landing command with the Start signal as well as from Digital Inputs and Freeze inputs. If you select
Freeze inputs, the command is activated on the encoder inputs (see the ADL300 Quick Start manual to identify the encode
Freeze inputs).
Rising (rising/positive edge) means active on the rising edge of the signal; Falling (falling/negative edge) active on the fall-
ing edge.
1110 Digit input E
1210 Digit input 1x
1212 Digit input 2x
1214 Digit input 3x
1216 Digit input 4x
1218 Digit input 5x
1220 Digit input 6x
1222 Digit input 7x
1224 Digit input 8x
1226 Digit input 9x
1228 Digit input 10x
1230 Digit input 11x
1232 Digit input 12x
3702 Run cont mon
3706 Down cont mon
3708 Brake cont mon
3714 Door open mon
6000 Null
6002 One
12250 B0 Lift decomp
12252 B1 Lift decomp
12254 B2 Lift decomp
12256 B3 Lift decomp
12258 B4 Lift decomp
12260 B5 Lift decomp
12262 B6 Lift decomp
12264 B7 Lift decomp
12266 B8 Lift decomp
12268 B9 Lift decomp
12270 B10 Lift decomp
12272 B11 Lift decomp
12274 B12 Lift decomp
12276 B13 Lift decomp
12278 B14 Lift decomp
12280 B15 Lift decomp
13000 F0 Rising
13001 F0 Falling
13002 F1 Rising
13003 F1 Falling
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.7.21 12102 Command input mon UINT32 0 ER FVS
The hexadecimal value of the input status is displayed, refer to the “lift control word” for a description of the meaning of each bit.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.7.22 12104 Command output mon UINT32 0 ER FVS
The hexadecimal value of the input status is displayed, refer to the “lift status word” for a description of the meaning of each bit.
