60 ADL300 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.6 1868 Analog out 2X mon cnt INT16 0 0 0 ER FVS
The actual value of the voltage or current present on analog output 2 of the expansion card is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.7 1874 An out 1X absolute ENUM INT16 Disable 0 1 ERW FVS
13.8 1876 An out 2X absolute ENUM INT16 Disable 0 1 ERW FVS
Enables the relative analog output as an absolute value. If this parameter is set to 1 the voltage on the analog output as-
sumes the value of 0...10V regardless of the sign of the command signal.
0 Disable
1 Enable
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.9 1882 Analog out 1X min cnt INT16 -16384 -32768 +32767 ERW FVS
13.10 1884 Analog out 1X max cnt INT16 -16384 -32768 +32767 ERW FVS
Setting of the minimum and maximum values for the analog output for the voltage present on analog output 1 of the expan-
sion card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.11 1890 Analog out 2X min cnt INT16 -16384 -32768 +32767 ERW FVS
13.12 1892 Analog out 2X max cnt INT16 16384 -32768 +32767 ERW FVS
Setting of the minimum and maximum values for the analog output in current or voltage present on analog output 2 of the
expansion card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.13 1898 Analog out 2X type ENUM -10V..+10V 0 2 ERW FVS
Selection of the programmed signal on analog output 2 of the expansion card. The standard output is coded for the signal
in voltage.
0 0..20mA
1 4..20mA
2 -10V..+10V
Select option 0 to apply a signal in current of 0 ... 20 mA to analog output 2. The signal must be positive.
Select option 1 to apply a signal in current of 4...20 mA to analog output 2.
Select option 2 to apply a maximum voltage of ±12.5V (typically ±10V/5mA) to analog output 2.
