ADV100 • Quick installation guide - Specifications and connection 101
A.2 - I/O Cards
● EXP-IO-D6A4R2-F-ADL (standard)
1 enable input (Enable) + 6 digital inputs (DI) + 2 analog inputs (AI) + 2 analog outputs (AO) + 2 relay outputs (RO).
The terminals of this card are not extractable.
EXP-IO-D6A4R2-F-ADL

T3

T2

T1
Commands
Associated parameter
1064,Driveready
1062,DriveOK
Associated parameter
Commands
Associated parameter
4500,Faultresetsrc
842,Multirefsel1src
840,Multirefsel0src
1044,FRreversesrc
1042,FRforwardsrc
RO
2O
RO
2C
RO
1O
RO
1C
AI
2N
AI
2P
AI
1N
AI
1P
AO
2N
AO
2P
AO
1N
AO
1P
-10
OUT
+10
OUT
DI 6 DI 5 DI 4 DI 3 DI 2 DI 1
EN
HW
DI
CM
OV
out
24
out
54 55 56 57 40 41 42 43 44 45 46 47 48 49 3 4 5 6 7 8 9 10 11 12
● EXP-IO-D4-ADL (optional)
1 enable input (Enable) + 2 digital inputs (DI) + 2 digital outputs (DO)
EXP-IO-D4-ADL

T1
Liftcommands
Associated parameter
1420, Dig output 6X src 1418, Dig output 5X src
Startreverse
Startforward
- -
DO
2
D0
1
DO
CM
DO
PS
DI
2
DI
1
EN
HW
DI
CM
OV
out
24
our
-- -- 26 27 28 29 7 8 9 10 11 12
● EXP-IO-D5R3-F-ADL (optional)
1 enable input (Enable) + 5 digital inputs (DI) + 3 relay outputs (RO).
The terminals of this card are not extractable.
EXP-IO-D5R3-F-ADL

T3

T1
Liftcommands
Associated parameter
1414, Dig output 3X src
RunContactor
1412, Dig output 2X src
BrakeContactor
1410, Dig output 1X src
DriveOK
Comandilift
Parametro associato
Multispeed1 Multispeed0
Emergency
Startreverse
Startforward
RO
3O
RO
3C
RO
2O
RO
2C
RO
1O
RO
1C
DI
5
DI
4
DI
3
DI
2
DI
1
EN
HW
DI
CM
OV
out
24
our
52 53 54 55 56 57 4 5 6 7 8 9 10 11 12
