74 ADV100 • Quick installation guide - Specifications and connection
11.2 Parameters list (Easy - Expert)
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
1 - MONITOR
1.1 250 Output current A FLOAT 16/32BIT 0.0 0.0 0.0 R FVS
1.2 252 Output voltage V FLOAT 16/32BIT 0.0 0.0 0.0 R FVS
1.3 254 Output frequency Hz FLOAT 16/32BIT 0.0 0.0 0.0 R FVS
1.4 628 Ramp setpoint rpm INT16 16/32BIT 0 0 0 R FVS
1.5 664 Speed setpoint rpm INT16 16/32BIT 0 0 0 R FVS
1.6 260 Motor speed rpm INT16 16/32BIT 0 0 0 R FVS
1.7 270 DC link voltage V FLOAT 16/32BIT 0.0 0.0 0.0 ER FVS
1.8 272 Heatsink temperature degC INT16 16BIT 0 0 0 ER FVS
1.9 280 Torque current ref A FLOAT 16/32BIT 0.0 0.0 0.0 ER F�S
1.10 282 Magnet current ref A FLOAT 16/32BIT 0.0 0.0 0.0 ER F�S
1.11 284 Torque current A FLOAT 16/32BIT 0.0 0.0 0.0 ER FVS
1.12 286 Magnet current A FLOAT 16/32BIT 0.0 0.0 0.0 ER FVS
1.13 3212 Motor overload accum perc UINT16 16/32BIT 0 0 100 ER FVS
1.14 368 Drive overload accum perc UINT16 16/32BIT 0 0 100 ER FVS
1.15 3260 Bres overload accum perc UINT16 16/32BIT 0 0 100 ER FVS
1.16 1066 Enable state mon BIT 16BIT 0 0 1 R FVS
1.17 1068 Start state mon BIT 16BIT 0 0 1 R FVS
1.18 1070 FastStop state mon BIT 16BIT 0 0 1 R FVS
1.19 1200 Digital input X mon UINT16 16BIT 0 0 0 R FVS
1.20 1400 Digital output X mon UINT16 0 0 0 R FVS
2 - DRIVE INFO
2.1 480 Drive series UINT16 7 0 0 R FVS
2.2 482 Drive size UINT16 0 0 0 RS FVS
2.3 484 Drive family ENUM No power 0 0 RS FVS
0 No power
1 230V..480V
2 500V..575V
3 690V
4 230V
2.4 486 Drive region ENUM EU 0 1 R FVS
0 EU
1 USA
2.5 488 Drive cont current A FLOAT CALCF 0.0 0.0 RZS FVS
2.6 490 Firmware ver.rel UINT16 0 0 0 R FVS
2.7 496 Firmware type UINT16 0 0 0 R FVS
2.8 504 Application ver.rel UINT16 0 0 0 ER FVS
2.9 506 Application type UINT16 0 0 0 ER FVS
2.10 510 Time drive power on h.min UINT32 0 0 0 ER FVS
2.11 512 Time drive enable h.min UINT32 0 0 0 ER FVS
2.12 514 Number power up UINT16 0 0 0 ER FVS
2.13 516 Time fan on h.min UINT32 0 0 0 ER FVS
2.14 520 Product S/N UINT32 0 0 0 R FVS
2.15 522 Regulation S/N UINT32 0 0 0 R FVS
2.16 524 Power S/N UINT32 0 0 0 R FVS
2.17 526 Power file ver.rel UINT16 0 0 0 ER FVS
2.18 530 Slot1 card type ENUM None 0 0 R FVS
0 None
257 I/O 1
1281 I/O 2
2305 I/O 3
3841 I/O 4
4865 I/O 5
5377 I/O 6
8 Enc 1
264 Enc 2
520 Enc 3
776 Enc 4
1032 Enc 5
4 Can/Dnet
255 Unknown
2.19 532 Slot2 card type ENUM None 0 0 R FVS
0 None
257 I/O 1
1281 I/O 2
2305 I/O 3
3841 I/O 4
4865 I/O 5
5377 I/O 6
8 Enc 1
