ADV100 • Quick installation guide - Specifications and connection 23
5.4 External EMC lter (optional)
The ADV100 inverter from size 4300 and higher is provided with an internal lter as standard,. Optional external lters
capable of enhancing system performance are listed in the table below.
Sizes Type Code
EN 61800-3 :
Category / Environment / Motor cable length
1040
EMI FTF-480-16
S7GHO C2/1°/30m
1055
EMI FTF-480-16
S7GHO C2/1°/30m
2075
EMI FTF-480-30
S7GHP C2/1°/30m
2110
EMI FTF-480-30
S7GHP C2/1°/30m
3150
EMI FTF-480-42
S7GOA C2/1°/30m
3185
EMI FTF-480-55
S7GOB C2/1°/30m
3220
EMI FTF-480-55
S7GOB C2/1°/30m
4300
EMI FTF-480-75
S7GOC C2/1°/30m
4370
EMI FTF-480-75
S7GOC C2/1°/30m
4450
EMI FTF-480-100
S7GOD C2/1°/30m
5550
EMI FTF-480-130
S7GOE C3/2°/100m
5750
EMI FTF-480-180
S7GOF C3/2°/100m
5900
EMI FTF-480-180
S7GOF C3/2°/100m
1040 ... 5900
ECF3
F4ZZ2 C4/2°/100m
5.5 External braking resistors (optional)
Recommended combinations for use with internal braking unit.
Size
List and technical data of standard external resistors
Resistor type Code Q.ty Max. overload, 1" -
service 10%
Ebr (kJ)
Max. overload, 30" -
service 25%
Ebr (kJ)
Pnbr
(W)
Rbr
(Ω)
Housing
1040 RFPD 750 DT 100R S8SY4 1 7,5 38 750 100 IP44
1055 RFPD 750 DT 68R S8T0CD 1 7,5 38 750 68 IP44
2075 RFPD 900 DT 68R S8SY5 1 9 48 900 68 IP44
2110 RFPD 1100 DT 40R S8SY6 1 11 58 1100 40 IP44
3150 RFPD 1900 D 28R S8SZS 1 19 75 1900 28 IP44
3185 BRT4K0-15R4 S8T00G 1 40 150 4000 15,4 IP20
3220 BRT4K0-15R4 S8T00G 1 40 150 4000 15,4 IP20
4300 BRT4K0-11R6 S8T00H 1 40 150 4000 11,6 IP20
4370 BRT4K0-11R6 S8T00H 1 40 150 4000 11,6 IP20
4450 BRT8K0-7R7 S8T00I 1 40 150 8000 7,7 IP20
5550
BRT8K0-7R7 S8T00I 1 40 150 8000 7,7 IP20
5750 ... 5900
External braking unit (BUy series, optional)
Pnbr Braking resistor rated power
Rbr Braking resistor ohmic value
Ebr Maximum energy that can be dissipated on the resistor
Braking resistors may be subject to unexpected overloads due to faults.
Resistors MUST be protected using thermal cutouts. These devices must not interrupt the circuit in which the resistor is
inserted but their auxiliary contact must cut off the power supply to the power section of the drive. If the resistor requires a
protection contact, this must be used together with that of the thermal cutout.
A la suite de pannes, les résistances de freinage peuvent être sujettes à des surcharges imprévues. La protection des résist-
ances au moyen de dispositifs de protection thermique est absolument capitale. Ces dispositifs ne doivent pas interrompre le
circuit qui abrite la résistance, mais leur contact auxiliaire doit couper l’alimentation du côté puissance du drive. Si la résist-
ance prévoit un contact de protection, ce dernier doit être utilisé conjointement à celui du dispositif de protection thermique.
Note! Refer to the Gefran Accessories catalogue (1S9I09) for resistor weights and dimensions.
Warning!
