6. Congurable control section
Cards for controlling and regulating the closed and open-loop power section. Commands, references and reactions
are connected to these.
7. Output voltage
Three-phase AC voltage.
8. Speed feedback encoder (see section 7.2.3 and Appendix)
2.2 Product identication
The basic technical data of the inverter are included in the product code and data plate
Name of model (code)
ADV 120 - 1 040 - X X X - F - 4 - C
CANBus:
C = included
Rated voltage:
4 = 400Vca
EMI FILTER:
X = not included
F = included
Software:
X = standard
Braking unit:
X = not included
B = included
Keypad:
X = not included
K = included
Inverter power in kW:
040 = 4kW
055 = 5,5kW
075 = 7,5kW
110 = 11kW
150 = 15kW
185 = 18.5kW
220 = 22kW
300 = 30kW
370 = 37kW
450 = 45kW
550 = 55kW
750 = 75kW
900 = 90kW
Mechanical dimensions of the drive:
1 = size 1
2 = size 2
3 = size 3
4 = size 4
5 = size 5
Regulation mode:
100 = BASIC, see Appendix
110 = FOC Sensorless
120 = FOC Closed loop
Inverter, ADV100 series
The inverter must be selected according to the rated current of the motor.
The rated output current of the drive must be higher than or equal to the rated current of the motor used.
The speed of the asynchronous motor depends on the number of pole pairs and frequency (plate and catalog data).
If using a motor at speeds above the rated speed, contact the motor manufacturer for any related mechanical problems
(bearings, unbalance, etc.). The same applies in case of continuous operation at frequencies of less than approx. 20
Hz (inadequate cooling, unless the motor is provided with forced ventilation).
Data plate
Type : ADV110-1040 -XXX S/N: 07012345
Inp: 230Vac-500Vac (Fctry set=400) 50/60Hz 3Ph
11A@400Vac 10A@480Vac
Out : 0-480Vac 500Hz 3Ph 4kW@400Vac 5 Hp @ 460Vac
9.5A @400V Ovld . 150%-60s 8.6A@460V Ovld.150%-60s
Drive model
Serial number
Input (mains supply, frequency, AC Input
Current at constant torque)
Output (Output voltage, frequency, power,
current, CT and VT overloads)
Approvals
IND. CONT. EQ.
31KF
