ADV100 • Quick installation guide - Specifications and connection 57
9.1 Asynchronous motor startup wizard
The ADV100 can operate with regulation modes: Voltage/Frequency (SSC) , Sensorless (open loop) and eld-oriented
vector control (closed loop).
Note! Before starting, check the factory settings:
Menu 02 DRIVE INFO, parameter 02.1 Drive series, PAR: 482, default=7.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 REFERENCES

02 DRIVE INFO
02/01 PAR: 480
Serie Drive
7
Menu 04 DRIVE CONFIG, parameter 04.2 Regulation mode, PAR: 552, default=V/f control.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 REFERENCES
 
x1
04 DRIVE CONFIG
04/02 PAR: 552
Regulation mode
V/ f control
Value: 0
The STARTUP WIZARD is a guided procedure used for quick start-up of the drive that helps to set the main
parameters.
It consists of a series of questions, relating to the various sequences for entering and calculating the parameters
necessary for correct drive pplication operation. The order of these sequences is as follows:
● Basic connections See step 1
● Setting motor parameters See step 2
● Self-tuning with rotating motor See step 3A
● Self-tuning with motor at stand-still or coupled to the load See step 3B
● Setting the maximum speed reference value See step 4
● Setting ramp parameters See step 5
● Saving parameters See step 6
● Speed test See step 7
The format of the function selection page is as follows:
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04
DRIVE CONFIG
05
REFERENCES

STARTUP WIZARD
Set motor data?
E=Yes Down=Next
Pressing the E key, the function to be programmed is accessed.
Press the ▼ (Down) key to move to the next function skipping the current function.
Press the ▲ (Up) key to return to the previous function.
To terminate the sequence of functions and return to the menu, press the ESC key.
The end of the start-up sequence is indicated with the page:
STARTUP WIZARD
End of se
q
uence!
Up=Back Down=Exit
Press the ▼(Down) key to exit the sequence and return to the menu.
Note ! In the procedures described below, the settings have been made using the ADV1..-2075 drive and a 10 Hp (7.36 kW) asynchronous motor.
