ADV100 • Quick installation guide - Specifications and connection 39
7.4.2 Typical connection diagram
EMERGENCY-OFF
EMERGENCY-OFF
K0
K0
S11
Off
S12
Stop
S2
ON / Start
ON / OFF
Start / Stop
K2
K2T
K2T
K2
G1
R11
R14
Drive ok
t = 1 s
K2
K1M
K1M
Mains contactor
L01
L00
Figure 7.4.3: Auxiliary control circuits
