ADV100 • Quick installation guide - Specifications and connection 17
4.6
Voltage level of the inverter for safe operations
The minimum time between the moment in which an ADV100 inverter is disabled from the mains and that in which an
operator can operate on internal parts of the inverter, without the danger of electric shock, is 5 minutes.
This value takes into account the time to turn off an inverter supplied at 460 Vac + 10%, without any options (time indicated for disabled
inverter condition).
4.7 Cooling
All inverters are tted with internal fans (+ 24V) and threshold control (ON @ 55°C and OFF @ 45°C).
Size Pv
(Heat dissipation)
Fan capacity
@Uln=230...460Vac (*) Heat sink (m
3
/h) Internal (m
3
/h)
1040 120 32 -
1055 160 2 x 56 -
2075 200 2 x 56 -
2110 250 2 x 32 -
3150 300 2 x 80 32
3185 380 2 x 80 32
3220 460 2 x 80 32
4300 600 2 x 250 2 x 50
4370 900 2 x 250 2 x 50
4450 1000 2 x 250 2 x 50
5550 1290 2 x 285 1 x 170
5750 1760 2 x 355 2 x 170
5900 2150 2 x 355 2 x 170
(*) values that refer to operation at default switching frequency.
Attention
