50 ADV100 • Quick installation guide - Specifications and connection
● Binary parameters (BIT type)
The parameter may assume only two states which are indicated as On-Off or 0-1.
13 DIGITAL OUTPUTS
14 ANALOG INPUTS
15 ANALOG OUTPUTS
16 MOTOR DATA
17 ENCODER CONFIG

x4
13
DIGITAL OUTPUTS
05/8 PAR: 1430
Dig out 1X inversion
O
f
f
E
13
DIGITAL OUTPUTS
05/8 PAR: 1430
Dig out 1X inversion
O
f
f

13
DIGITAL OUTPUTS
05/8 PAR: 1430
Dig out 1X inversion
On
Press E to activate modication mode. The entire line is displayed in reverse. Use the ▲ and ▼ keys to move from one
state to another. Press E to conrm the modication or ESC to cancel.
● LINK parameters
The parameter may assume the number of another parameter as value.
13 DIGITAL OUTPUTS
14 ANALOG INPUTS
15 ANALOG OUTPUTS
16 MOTOR DATA
17 ENCODER CONFIG

13 DIGITAL OUTPUTS
01/8 PAR: 1410
Dig output 1X src
»Drive OK
Value: 1062
E
13 DIGITAL OUTPUTS
01/8 PAR: 1410
Dig output 1X src
»Drive OK
Value: 1062

13 DIGITAL OUTPUTS
01/8 PAR: 1410
Dig output 1X src
»Dig ou
t
put 1X src
Value: 1232

13 DIGITAL OUTPUTS
01/8 PAR: 1410
Dig output 1X src
»
Drive ready
Value: 1064
Press E to activate modication mode. The entire line is displayed in reverse. The elements of the list of parameters
associated with this parameter can be scrolled using the ▲ and ▼ keys.
Press E to conrm the modication or ESC to cancel.
● ENUM parameters
The parameter may assume only the values contained in a selection list.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 REFERENCES
 
x2
04 DRIVE CONFIG
03/20 PAR: 554
Access mode
Easy
Value: 0
E

04 DRIVE CONFIG
03/17 PAR: 554
Access mode
Ex pert
Value: 1
Press E to activate modication mode. The entire line is displayed in reverse. The elements of the selection list can be
scrolled using the ▲ and ▼ keys.
Press E to conrm the modication or ESC to cancel.
● Execution of commands
A parameter can be used to carry out a number of operations on the drive. For an example, see paragraph 8.4: in this
case the request "Press E to execute" is displayed.
To execute the command, press E. During execution of the command, the “In progress” caption is displayed to
indicate that the operation is in course. At the end of execution, if the result is positive, the “Done” caption is displayed
for few seconds. If execution has failed, an error message is displayed.
8.4 How to save parameters
There are two ways of saving parameters in the non-volatile memory of the drive:
1) By pressing the SAVE key on the keypad.
2) Menu 04 DRIVE CONFIG, parameter 04.01 Save parameters, PAR : 550. This is used to save changes to param-
eter settings so that they are maintained even after power-off.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 REFERENCES

04 DRIVE CONFIG
01/20 PAR: 550
Save parameters
Press E to exe
c
ute
E
04 DRIVE CONFIG
01/20 PAR: 550
Save parameters
In progress
04 DRIVE CONFIG
01/20 PAR: 550
Save parameters
Done
To exit, press the ◄ key.
